KSYRIUM S

Name: KSYRIUM S RB 700 QR M11
Brand: Mavic
SKU: P1325155
Price: 3499.9 USD
Availability: OutOfStock
Rating: 4.8 (293 reviews)

Trusted Mavic technologies and design, all packaged in a lightweight, durable wheelset with a stunning finish make this a smart upgrade for any road rider

More information

Lightweight and durable for everyday performance
Laterally stiff and vertically compliant for a more dynamic ride
Improved UST Road delivers more speed, comfort and control in an easy to use tubeless system

Weight Pair : 1570gWeight Front : 675gWeight Rear : 895g

Rim BrakeBraking

9X100-130Axle (mm)

Be alerted as soon as the product is available

Split into 4 payments, no fee

Any questions?Contact our customer service department.

Shipped within 24 hours
Money back guarantee
Free delivery from $99.00
2-year warranty

This lightweight aluminum wheelset is a no brainer for anybody looking to make an easy upgrade from OEM wheels. The Ksyrium S can significantly boost any bike's performance and is an easy entry point to Mavic quality that doesn't take any shortcuts.

The Ksyrium S is 60g lighter than the former Ksyrium UST while also being wider, stronger and laterally stiffer. Stiffness is optimized using Fore technology. The upper bridge remains undrilled, optimizing strength and rigidity, and it doesn’t require the use of a rim tape, which saves another 30g per wheel. The rim bed’s new shape makes it easier than ever to mount and remove tires, and our UST Tubeless technology improves rolling resistance and grip while reducing the risk of punctures. Those rims are made in France, in our aluminum rim factory.

Our new Infinity hub platform optimizes stiffness and power transfer with highly controlled spoke tension, while an Instant Drive 360 freewheel coupled with our automatic bearing preload adjustment (QRM Auto) delivers fast engagement and durability. The Ksyrium S doesn’t just ride fast, it looks fast too. Matte painted hubs, invisible rim welding and deep black spokes give this wheelset a premium look that stands out from the crowd.
It's available for Shimano cassettes, and can convert to Campagnolo or XD-Road with optional driver bodies.

Main features

Lightweight and durable for everyday performance

Rim weighs only 430g
No rim tape is needed, saving 60g over a traditional wheel
Flat, lightweight spokes and ID360 freewheel technology

Laterally stiff and vertically compliant for a more dynamic ride

Fore technology keeps the rim upper bridge solid to make the 19mm wide rim stiffer
New Infinity hub plaform: stiff axle, durable bearings and new hub design

Improved UST Road delivers more speed, comfort and control in an easy to use tubeless system

No tubes means less friction, better efficiency and grip, a reduced risk of punctures
New rim bed shape makes it easier to mount and change tires
Fore drilling technology doesn't require the use of rim tape

Specifications

Weight Pair : 1570 g
Weight Front : 675 g
Weight Rear : 895 g

Material: Maxtal
Height: 22 mm
Joint: SUP welding technology
Internal width: 19 mm
Drilling : Fore tapeless tubeless technology (front 18 holes and rear 24 holes)
Braking: pads
ETRTO size: 622x19TC
Tire: UST Tubeless Ready

Material: steel
Shape: straight, extra-flat, ADR + constricted (front and rear opposite freewheel side)
Shape: straight, extra-flat, constricted, antirot (rear freewheel side)
Nipples: brass, black
Screw: M7
Lacing: radial (front) - Isopulse (rear)

Body material: aluminium
Body design: INFINITY
Axle material: aluminum
Axle size: front 9x100 / rear 9x130 - Quick release only
Freewheel technology: Instant Drive 360
Freewheel: Shimano HG road
Bearing technology: QRM automatic setting - sealed cartridge

Freewheel body: convertible SRAM XD road (kit V2580101 sold separately)
Freewheel body: convertible SHIMANO HG light road (kit V3850101 sold separately)
Freewheel body: convertible SHIMANO MS (kit V3990101 sold separately)
Freewheel body: convertible CAMPAGNOLO ED (kit V3440101 sold separately)
Freewheel body: convertible CAMPAGNOLO N3W (kit V4270101 sold separately)

User guide
Quick release level 1
UST valve not mounted on wheel
2 Multifonction adjustment wrench with the rear wheel

Minimum tyre size: width 23mm - pressure max. 6.75Bar/97PSI
Maximum tyre size: width 62mm - pressure max. 3.8Bar/55PSI
ASTM category 2 : road and offroad with jumps less than 15cm
Maximum weight supported by the wheels: must not exceed 120 kg (bike weight included)

LightnessMaxtal aluminum alloy

Light and strong. Exclusive to Mavic, this specific aluminum alloy offers a higher strength to weight ratio than conventional 6106 alloy.

LightnessISM light rim technology

Inter Spoke Milling is an exclusive Mavic patented concept. The ISM involves the machining of the lower bridge of the rim between each spoke hole to create a light and rigid rim without reducing the durability of the rim.

Efficiency RigidityFore tapeless tubeless technology

Stiffer and stronger. Instead of being drilled, the lower rim bridge is pushed up on the inside, then threaded to enable the spoke nipples to be directly screwed in it, leaving the upper rim bridge intact.

Efficiency RigidityInstant Drive 360 freewheel technology

The new Instant Drive 360 freewheel system is super light and efficient. A large contactless rubber seal provides low friction, while a wide array of end caps makes it super versatile.

Efficiency RigidityIsopulse lacing design

Optimum energy transfer. The spokes are laced radially on the drive side and crossed 2 on the non drive side to maximise drive side dish, thus providing a better spoke tension balance between left and right flanges.

Efficiency RigidityUST tubeless technology

Traction and control. Universal Standard for Tubeless. Ready to ride tubeless system. The UST concept improves traction, control and comfort whilst reducing inertia and flats.

Safety ReliabilitySUP welding technology

Soudé Usiné Process, stronger and smoother joint. After bending, the rim joint is arc welded. The welded seam is then milled for a smooth finish.

Safety ReliabilityInfinity hub design

Efficient power transfer thanks to optimised non-contact spoke lacing (no noise under load) and tension distribution. The length of the spokes at the front and rear is identical. Maintenance is easy thanks to a tool-free solution.

Safety ReliabilityQRM Auto bearing preload technology

Qualité de Roulements Mavic Auto. Those cartridge bearings are of course double sealed with C3 internal clearance. Their preload is automatically adjusted to guarantee a perfect spin with no play on the long run.

User guides and documents

General User GuideDownload PDF
